45 Degree Elbow Buttweld Fitting

Omaa Metal Sources is snappiest making producer of Carbon Steel 45 Degree Elbow remained mindful of by Saudi Aramco. We are most fundamental inspector of Alloy Steel 45 Degree Pipe Elbow.Omaa Metal Sources is most undeniable exporter of Incoloy 800 45 Degree Reducing Elbow, Hastelloy 45 Degree Weld Elbow in different sizes. Purchase from our set up stock Stainless Steel 304l 45 Degree Elbow, most ideal condition, cost in India, notice our cost of Inconel 600 45 Degree Elbow including Short Radius Aluminum Elbow, Stainless Steel 317 Short Radius Elbow and Copper Nickel Cu-ni 70/30 Short Radius Elbow. We have figured out deftly of ELBOW Short Radius BW Schedule 120 ASTM A234 GR.WPB, ASME B16.9.

45 Degree Elbow,45 Degree Elbow Manufacturers, 45 Degree Elbow Exporters, 45 Degree Elbow Suppliers, 45 Degree Elbow Stockists,45 Degree Elbow Buttweld Fittings Manufacturers, 45 Degree Elbow Buttweld Fittings Exporters, 45 Degree Elbow Buttweld Fitting Suppliers, 45 Degree Elbow Buttweld Fitting Stockists.

Awesome Image

A Stainless Steel 45 degree Elbow, in any case called a "45 breeze" or "45 ell", is routinely utilized in water-deftly working conditions, food, substance and electronic present day pipeline affiliations, cooling pipelines, development and nursery creation, and sun controlled energy office including. Elbows are in like way insinuated by length. The degree of condition of a long-make (LR) elbow is 1.5 occasions the line bunch over, notwithstanding a short-clear (SR) elbow has an extension tantamount to the line broadness. Short elbows, absolutely open, are routinely utilized in compacted plans, and in genuinely close zones.

In the event that you are searching for best cost of ASME B16.9 45 Degree Elbow or ANSI Short Radius Elbow, Short Radius Copper Elbow close to you with briefest time transport or free event of ASTM A234 WP91 Alloy Steel Short Radius Elbow. Call us for Latest and Updated regard List of Duplex Steel Uns S31803 Short Radius Elbow and SS 304 45 Degree Short Radius Elbow.

Our 45° Short Radius Elbow are available to our tremendous clients in various degree of breadths, divider thicknesses and sizes in changed advancement other than at moderate rates. By then, we offer various kinds of these fitting, for example, ASME B16.9 SR Weld Elbow, Inconel 45 Degree Elbow, Carbon Steel 45 Degree Elbow, Alloy Steel 45 Degree Short Radius Elbow.

45 Degree Elbow Buttweld Fitting Manufacturers in Mumbai, 45 Degree Elbow Buttweld Fitting Exporters in Mumbai, 45 Degree Elbow Buttweld Fitting Suppliers in Mumbai, 45 Degree Elbow Buttweld Fitting Stockists in Mumbai.

Specification of 45 Degree Elbow

Specifications 45 Degree Elbow
45 Degree Weld Elbow Pipe Fittings size Seamless Butt Weld Fittings: 1/2" - 10"
Welded Butt Weld Fittings: 1/2" - 48"
45 Degree Elbow Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
45 Degree Pipe Elbow Thickness SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
45 Degree Weld Elbow Types Seamless / ERW / Welded / Fabricated Pipe Fittings
45 Degree Reducing Elbow Type DN15-DN1200
Connection Welding
Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom Pipe Fittings
Size Range ½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100)
45 Degree Elbow Fittings Angle : 22.5 deg, 30deg, 45 deg, 90 deg, 180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D, 4D, 5D, 6D, 7D-40D.
Standard: ASME B16.9, ASME B16.28, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO
Manufacturing process Push, Press, Forge, Cast, etc.
45 Degree Weld Elbow Fittings Test Certificates EN 10204/3.1B
Raw Materials Certificate
100% Radiography Test Report
Third Party Inspection Report, etc
Origin & Mills Japanese, Indian, USA, Korean, European, Ukraine, Russian
Key markets and industries for 45 Degree Elbow
  • Bitumen upgraders.
  • Heavy oil refineries.
  • Nuclear power (mostly seamless).
  • Petrochemicals and acids.
Application
  • Fittings To Connect Pipe & Tubes in Petroleum, Power, Chemical, Construction, Gas, Metallurgy, Shipbuilding etc
  • ASME B16.9 Schedule 10 45 Degree Elbow are an economical alternative for lower-pressure applications.
  • ANSI B16.9 Schedule 40 45 Degree Elbow have a thicker wall for higher-pressure applications.
Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175

Material of 45 Degree Elbow

Prestige quality 45 Degree Pipe Elbow manufacturers in India offer these Carbon Steel 45 Degree Pipe Elbow in DIN, EN, BS, ISO, JIS or ANSI standard.

Carbon Steel 45 Degree Elbow
  • ASTM A234 WPB 45 Degree Elbow
  • ASTM A420 WPL6 45 Degree Pipe Elbow
  • WPHY 42 45 Degree Reducing Elbow
  • WPHY 52 45 Degree Elbow
  • WPHY 60 45 Degree Weld Elbow
  • WPHY 65 45 Degree Weld Elbow
  • WPHY 70 45 Degree Pipe Elbow
Stainless Steel 45 Degree Elbow
  • ASTM A403 WP304 45 Degree Pipe Elbow
  • ASTM A403 WP304L 45 Degree Weld Elbow
  • ASTM A403 WP316 45 Degree Elbow
  • ASTM A403 WP316L 45 Degree Pipe Elbow
  • ASTM A403 WP317 45 Degree Weld Elbow
  • ASTM A403 WP317L 45 Degree Pipe Elbow
  • ASTM A403 WP321 45 Degree Pipe Elbow
  • ASTM A403 WP321H 45 Degree Weld Elbow
  • ASTM A403 WP347 45 Degree Elbow
  • ASTM A403 WP347H 45 Degree Reducing Elbow
Alloy Steel 45 Degree Pipe Elbow
  • ASTM A234 WP5 45 Degree Weld Elbow
  • ASTM A234 WP9 45 Degree Elbow
  • ASTM A234 WP11 45 Degree Elbow
  • ASTM A234 WP22 45 Degree Weld Elbow
  • ASTM A234 WP91 45 Degree Pipe Elbow
Inconel 45 Degree Weld Elbow
  • Inconel 600 45 Degree Elbow
  • Inconel 601 45 Degree Pipe Elbow
  • Inconel 625 45 Degree Reducing Elbow
  • Inconel 718 45 Degree Pipe Elbow
  • Inconel x750 45 Degree Elbow
Copper 45 Degree Elbow T1, T2, C10100, C10200, C10300, C10400, C10500, C10700, C10800, C10910,C10920, TP1, TP2, C10930, C11000, C11300, C11400, C11500, C11600, C12000,C12200, C12300, TU1, TU2, C12500, C14200, C14420, C14500, C14510, C14520, C14530, C17200, C19200, C21000, C23000, C26000, C27000, C27400, C28000, C33000, C33200, C37000, C44300, C44400, C44500, C60800, C63020, C68700, C70400, C70600, C70620, C71000, C71500, C71520, C71640, etc
Copper Nickel 45 Degree Pipe Elbow Copper Nickel 90/10 (C70600 ) 45 Degree Pipe Elbow, Cupro Nickel 70/30 (C71500) 45 Degree Elbow, UNS C71640 45 Degree Elbow
Brass 45 Degree Reducing Elbow 3602 / 2604 / H59 / H62 / etc.
Hastelloy 45 Degree Weld Elbow Hastelloy C276 (UNS N10276) 45 Degree Elbow, C22 (UNS N06022) 45 Degree Pipe Elbow, C4 45 Degree Elbow, C2000 45 Degree Weld Elbow, B2 45 Degree Elbow, B3 45 Degree Elbow, X 45 Degree Reducing Elbow
Monel 45 Degree Weld Elbow Monel 400 (UNS No. N04400) 45 Degree Elbow, Monel 500 (UNS No. N05500) 45 Degree Weld Elbow
Alloy 20 45 Degree Elbow Carpenter® 20 Alloy 45 Degree Weld Elbow, Alloy 20Cb-3 45 Degree Pipe Elbow
Aluminium 45 Degree Weld Elbow 5052 /6061/ 6063 / 2017 / 7075 / etc.
Nickel 45 Degree Pipe Elbow Nickel 200 45 Degree Elbow, Nickel 201 45 Degree Reducing Elbow
Duplex 45 Degree Weld Elbow S31803 / S32205 A182 Gr F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F61
Super Duplex 45 Degree Elbow S32750 / S32760 A182 Gr F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F61
Incoloy 45 Degree Elbow Incoloy 800 45 Degree Reducing Elbow, Incoloy 800H 45 Degree Elbow, Incoloy 800HT (UNS N08800) 45 Degree Weld Elbow, Incoloy 825 (UNS N08825) 45 Degree Pipe Elbow
254 Smo 45 Degree Pipe Elbow SMO 254/6Mo 45 Degree Elbow, UNS S31254 45 Degree Elbow, DIN 1.4547 45 Degree Weld Elbow
Nimonic 45 Degree Weld Elbow Nimonic 75 45 Degree Elbow, Nimonic 80A 45 Degree Elbow, Nimonic 90 45 Degree Pipe Elbow
Other 45 Degree Reducing Elbow material Tin bronze 45 Degree Weld Elbow, Alumunum bronze 45 Degree Weld Elbow, Lead bronze 45 Degree Weld Elbow
Titanium 45 Degree Pipe Elbow
  • ASTM B381 Titanium Gr. 1 45 Degree Pipe Elbow
  • ASTM B381 Titanium Gr. 2 45 Degree Weld Elbow
  • ASTM B381 Titanium Gr. 4 45 Degree Weld Elbow
  • ASTM B381 Titanium Gr. 5 45 Degree Elbow
  • ASTM B381 Titanium Gr. 7 45 Degree Pipe Elbow

ASTM Specification of 45 Degree Elbow

  •  Carbon Steel 45 Degree Weld Elbow
    •  ASTM A234 WPB 45 Degree Elbow
    •  ASTM A420 WPL6 45 Degree Reducing Elbow
  •  Alloy Steel High-Temp 45 Degree Weld Elbow
    •  ASTM A234 WP5 45 Degree Elbow
    •  ASTM A234 WP11 45 Degree Pipe Elbow
    •  ASTM A234 WP9 45 Degree Reducing Elbow
    •  ASTM A234 WP22 45 Degree Pipe Elbow
    •  ASTM A234 WP91 45 Degree Elbow
  •  Austenitic Stainless Steel 45 Degree Elbow
    •  ASTM A403 Gr WP304 45 Degree Weld Elbow
    •  ASTM A403 Gr WP316 45 Degree Reducing Elbow
    •  ASTM A403 Gr WP321 45 Degree Elbow
    •  ASTM A403 Gr WP347 45 Degree Pipe Elbow
    •  ASTM A403 Gr WP304L 45 Degree Pipe Elbow
    •  ASTM A403 Gr WP316L 45 Degree Pipe Elbow
    •  ASTM A403 Gr WP317 45 Degree Reducing Elbow
    •  ASTM A403 Gr WP317L 45 Degree Weld Elbow
    •  ASTM A403 Gr WP321 45 Degree Weld Elbow
    •  ASTM A403 Gr WP310 45 Degree Pipe Elbow
    •  ASTM A403 Gr WP347 45 Degree Elbow
  •  Nickel Alloy 45 Degree Weld Elbow
    •  ASTM B564 45 Degree Pipe Elbow
    •  astm b564 uns n06600 45 Degree Elbow
    •  astm b564 uns n06625 45 Degree Elbow
    •  astm b564 uns no4400 45 Degree Weld Elbow
    •  astm b564 uns n08810 45 Degree Reducing Elbow
    •  astm b564 uns n08811 45 Degree Weld Elbow
    •  astm b564 uns n08825 45 Degree Elbow
    •  astm b564 uns n04400 45 Degree Pipe Elbow
    •  astm b564 uns n10276 45 Degree Elbow
    •  astm b564 uns n10665 45 Degree Weld Elbow

Dimensions of 45 Degree Elbow

ASME B16.9 45° Short Radius Elbow Manufacturer
Nom.
Pipe
Size
Pipe
Sched.
or No.
Center-
to-end
Dimen.
Outside
Dia.
Inside
Dia.
Wall
Thick.
Approx.
Weight
(lb.)
F OD ID T
STANDARD WEIGHT
1/2 40 5/8 0.840 0.622 0.109 0.1
3/4 40 7/16 1.050 0.824 0.113 0.1
1 40 7/8 1.315 1.049 0.133 0.2
1 1/4 40 1 1.660 1.380 0.140 0.4
1 1/2 40 1 1/8 1.900 1.610 0.145 0.5
2 40 1 3/8 2.375 2.067 0.154 0.9
2 1/2 40 1 3/4 2.875 2.469 0.203 1.5
3 40 2 3.500 3.068 0.216 2.5
3 1/2 40 2 1/4 4.000 3.548 0.226 3.5
4 40 2 1/2 4.500 4.026 0.237 4.8
5 40 3 1/8 5.563 5.047 0.258 7.8
6 40 3 3/4 6.625 6.065 0.280 12
8 40 5 8.625 7.981 0.322 23
10 40 6 1/4 10.750 10.020 0.365 42
12 – 7 1/2 12.750 12.000 0.375 61
14 30 8 3/4 14.000 13.250 0.375 79
16 30 10 16.000 15.250 0.375 103
18 – 11 1/4 18.000 17.250 0.375 132
20 20 12 1/2 20.000 19.250 0.375 160
22 20 13 1/2 22.000 21.250 0.375 195
24 20 15 24.000 23.250 0.375 238
EXTRA STRONG
Nom.
Pipe
Size
Pipe
Sched.
or No.
Center-
to-end
Dimen.
Outside
Dia.
Inside
Dia.
Wall
Thick.
Approx.
Weight
(lb.)
F OD ID T
1/2 80 5/8 0.840 0.546 0.147 0.2
3/4 80 7/16 1.050 0.742 0.154 0.3
1 80 7/8 1.315 0.957 0.179 0.4
1 1/4 80 1 1.660 1.278 0.191 0.5
1 1/2 80 1 1/8 1.900 1.500 0.200 0.6
2 80 1 3/8 2.375 1.939 0.218 1.1
2 1/2 80 1 3/4 2.875 2.323 0.276 2.1
3 80 2 3.500 2.900 0.300 3.5
3 1/2 80 2 1/4 4.000 3.364 0.318 4.8
4 80 2 1/2 4.500 3.826 0.337 6.5
5 80 3 1/8 5.563 4.813 0.375 11
6 80 3 3/4 6.625 5.761 0.432 18
8 80 5 8.625 7.625 0.500 35
10 60 6 1/4 10.750 9.750 0.500 56
12 – 7 1/2 12.750 11.750 0.500 80
14 – 8 3/4 14.000 13.000 0.500 100
16 40 10 16.000 15.000 0.500 131
18 – 11 1/4 18.000 17.000 0.500 172
20 30 12 1/2 20.000 19.000 0.500 210
22 30 13 1/2 22.000 21.000 0.500 259
24 – 15 24.000 23.000 0.500 302

Weight Chart Of 45 Degree Pipe Elbow

WEIGHTS OF FITTINGS
NPS
inches		 ELBOWS
LR 45°		 ELBOWS
SR 45°
Sch.
5S		 Sch.
10S		 Sch.
40S		 Sch.
80S		 Sch.
5S		 Sch.
10S		 Sch.
40S		 Sch.
80S
1/2 0.05 0.06 0.08 0.10 0.03 0.04 0.05 0.07
3/4 0.06 0.07 0.09 0.11 0.04 0.05 0.06 0.07
1 0.09 0.15 0.18 0.20 0.06 0.10 0.12 0.13
1 1/4 0.13 0.20 0.25 0.35 0.09 0.13 0.17 0.12
1 1/2 0.18 0.30 0.40 0.50 0.12 0.20 0.27 0.33
2 0.30 0.50 0.70 0.90 0.20 0.33 0.47 0.60
2 1/2 0.60 0.85 1.35 1.80 0.40 0.60 0.90 1.20
3 0.90 1.30 2.00 2.90 0.60 0.90 1.35 1.90
4 1.40 2.00 4.00 5.90 0.90 1.35 2.65 3.90
5 2.90 3.60 6.50 9.70 1.95 2.40 4.35 6.50
6 4.00 5.00 10.5 16.0 2.70 3.35 7.00 10.5
8 7.40 10.0 21.5 33.5 4.90 6.70 14.5 22.5
10 13.6 16.8 38.5 52.5 9.10 11.2 25.6 35.0
12 23.4 27.0 59.0 79.0 15.6 18.0 39.5 53.0
14 29.0 35.0 70.0 94.0 19.3 23.5 47.0 63.0
16 41.3 47.0 95.0 125 27.5 31.5 63.5 84.0
18 51.8 59.0 120 158 34.5 39.5 80.0 105
20 73.0 85.0 146 194 49.0 57.0 98.0 129
24 122 140 210 282 82.0 94.0 140 188
Approximate weights in kg, density 8 kg/dm3

45 Degree Elbow Buttweld Fitting Manufacturers in India, 45 Degree Elbow Buttweld Fitting Exporters in India, 45 Degree Elbow Buttweld Fitting Suppliers in India, 45 Degree Elbow Buttweld Fitting Stockists in India.
