Omaa Metal Sources is an expert manufacturer of treated steel flexible hose lines and development joints, with ribs, camlock couplings, association, nuts and areolas as end affiliations. We are one of the most rumored ss adaptable hose pipe creator and exporter in India. We stock and easily hardened steel flexible hoses in AISI 321, 316, 316L and 304 evaluations change as per generally speaking quality norms. Our game plan and get together of hose is noteworthy, which guarantees most noticeable cycle life of the hose, at most certified rates. We can make an inspiration to our customers with quality things and real costs for cemented steel adaptable hose pipes. All our adaptable hoses are 100% hydro endeavored and impervious.
SS Flexible Hoses Pipes, SS Flexible Hoses Pipes Manufacturers, SS Flexible Hoses Pipes Exporters, SS Flexible Hoses Pipes Suppliers, SS Flexible Hoses Pipes Stockists.Stainless Steel Flexible Hose Pipes Manufacturers Suppliers – Top Quality SS Wire Braided Hose Pipes in India.
SS Flexible Hoses Pipes Manufacturers in Mumbai, SS Flexible Hoses Pipes Exporters in Mumbai, SS Flexible Hoses Pipes Suppliers in Mumbai, SS Flexible Hoses Pipes Stockists in Mumbai.SS Flexible Corrugated Metallic Hose Pipes & Assemblies – Specification BS 6501 / ISO 10380 –
Omaa Metal Sources is a primary producer and supplier of solidified steel (SS) versatile hose social occasions, in any case called versatile metal hose gatherings. We offer a complete extent of ss versatile hose pipes from size 1/4" ID to 12" ID in SS 304, 321, 316 & 316L, made in consistence with BS 6501, Part-1. Our treated steel hose social events are available with a wide extent of end affiliations, bore sizes and lengths. We can smoothly wrinkled tempered steel hose assemblies that meets your most mentioning particular conclusions.
At Omaa Metal Sources, flexible hose are available in various grades, and wide range of end connections such below:
- Stainless Steel Flexible Hose Pipe with Flange End Connections – Round Flange, Square Flange, Vacuum Flange
- Stainless Steel Flexible Hose Pipe with Union Fittings – Stainless Steel Union, Mild Steel Union
- Stainless Steel Flexible Hose Pipe with Threaded Fittings – BSP, BSPT, NPT
- Stainless Steel Flexible Hose Pipes with Tri Clover Fittings – TC Ferrule, Tri Clamp, Gaskets
- Stainless Steel Flexible Hose Pipes with Camlock & Quick Release Couplings
- Stainless Steel Flexible Hose Pipes with Long Pipe Ends, Bends, Elbows, Reducer
Specifications of Stainless Steel Flexible Hose Pipe
| Product | Stainless Steel Flexible Hose Pipes |
| Grades | AISI 321, AISI 304, AISI 316L |
| End Connections | Flanges, Threaded Fittings, Camlock Couplings, Quick Release Couplings |
| Hose ID (in inch) | 1/4″, 3/8″, 1/2″, 5/8″, 3/4″, 1″, 1.25″, 1.5″, 2″, 3″, 4″, 5″, 6″, 8″, 10″, 12″, 14″, 20″ |
| Specification | BS 6501, PART-1:2004/ISO 10380 : 2012 |
| Temperature | -200 to 500 Degree Celsius |
| Pressure Rating | High, Low, Medium |
| Services | Hydro Testing, Pneumatic Test, PMI Testing |
Technical Data, Pressure Rating for Stainless Steel Flexible Hose Pipes
| SIZE | SINGLE BRAID | DOUBLE BRAID | |||||||||
| Nominal Size | Static | Dynamic bend radius | Max. working | Test pressure | Burst | Static | Dynamic bend radius | Max. working | Test pressure | Burst | |
| bend radius | pressure | pressure | bend radius | pressure | pressure | ||||||
| Inch | mm | mm | mm | bar | bar | bar | mm | mm | bar | bar | bar |
| 1/4 | 6 | 25 | 100 | 154 | 230 | 616 | 25 | 100 | 246 | 369 | 984 |
| 3/8 | 10 | 40 | 150 | 105 | 157 | 420 | 40 | 150 | 168 | 252 | 672 |
| 1/2 | 12 | 50 | 200 | 88 | 132 | 352 | 50 | 200 | 140 | 210 | 560 |
| 5/8 | 16 | 50 | 200 | 73 | 109 | 292 | 50 | 200 | 116 | 174 | 464 |
| 3/4 | 20 | 70 | 200 | 64 | 96 | 256 | 70 | 200 | 102 | 153 | 408 |
| 1 | 25 | 90 | 200 | 50 | 75 | 200 | 90 | 200 | 80 | 120 | 320 |
| 1¼ | 32 | 110 | 250 | 42 | 63 | 168 | 110 | 250 | 67 | 100 | 268 |
| 1 ½ | 40 | 130 | 250 | 32 | 48 | 128 | 130 | 250 | 51 | 76 | 204 |
| 2 | 50 | 175 | 350 | 31 | 46 | 124 | 175 | 350 | 49 | 73 | 196 |
| 2 ½ | 65 | 200 | 410 | 26 | 39 | 104 | 200 | 410 | 41 | 61 | 164 |
| 3 | 80 | 205 | 450 | 18 | 27 | 72 | 205 | 450 | 28 | 42 | 112 |
| 4 | 100 | 230 | 560 | 16 | 24 | 64 | 230 | 560 | 26 | 39 | 104 |
| 5 | 125 | 280 | 660 | 16 | 24 | 64 | 280 | 660 | 25 | 37 | 100 |
| 6 | 150 | 320 | 815 | 12 | 18 | 48 | 320 | 815 | 20 | 30 | 80 |
| 8 | 200 | 435 | 1015 | 10 | 16 | 40 | 435 | 1015 | 16 | 24 | 64 |
| 10 | 250 | 560 | 1220 | 6.5 | 10 | 26 | 560 | 1220 | 10.5 | 16 | 42 |
Applications of Corrugated SS Flexible Hose Pipes
- Off-Shore Oil Drilling Companies
- Power Generation
- Petrochemicals
- Gas Processing
- Specialty Chemicals
- Pharmaceuticals
- Pharmaceutical Equipment
- Chemical Equipment
- Sea Water Equipment
- Heat Exchangers
- Condensers
- Pulp and Paper Industry
