Specification of Rtj Weld Neck Flanges
| ASME B16.5 Ring Type Joint Flanges Size Chart | 1/2" (15 NB) to 48" (1200NB) DN10~DN5000 |
|---|---|
| Rtj Blind Flange Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092 |
| Rtj Weld Neck Flange Pressure Rating ANSI | Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS Ring Type Joint Orifice Flange |
| Rtj Flange Pressure Calculation in DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 Rtj Weld Neck Flange |
| JIS | 5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K Rtj Flange |
| UNI | 6Bar 10Bar 16Bar 25Bar 40Bar Rtj Blind Flange |
| EN | 6Bar 10Bar 16Bar 25Bar 40Bar Weld Neck Ring Type Joint Flange |
| Coating | Oil Black Paint, Anti-rust Paint, Zinc Plated, Yellow Transparent, Cold and Hot Dip Galvanized |
| Most common types of Ring Type Joint Weld Neck Flange | Forged / Threaded / Screwed / Plate |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Production technique |
|
| Connect Type/ Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, Groove |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine, Sand-blasting machine etc |
| Origin | Indian / West Europe / Japan / USA / Korean |
| Manufacturer of | ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc.
|
| Rtj Blind Flange Uses & application |
|
| Export to | Ireland, Singapore, Indonesia, Ukraine, Saudi Arabia, Spain, Canada, USA, Brazil, Thailand, Korea, Iran, India, Egypt, Oman, Dubai, Peru, etc |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
Material of Rtj Flange
- Carbon Steel Ring Type Joint Orifice Flange
- A105 Ring Type Joint Flanges
- Alloy Steel High-Temp Rtj Flange
- A182 Gr F1 Rtj Blind Flange
- A182 Gr F11 Rtj Weld Neck Flange
- A182 Gr F12 Ring Type Joint Orifice Flange
- A182 Gr F22 Ring Type Joint Flanges
- A182 Gr F5 Ring Type Joint Weld Neck Flange
- A182 Gr F9 Rtj Flange
- Alloy Steel Low-Temp
Weld Neck Ring Type Joint Flange
- A350 Gr LF2 Rtj Weld Neck Flange
- A350 Gr LF3 Ring Type Joint Flanges
- Austenitic Stainless Steel RTJ Flanges
- A182 Gr F304 Weld Neck Ring Type Joint Flange
- A182 Gr F316 Rtj Flange
- A182 Gr F321 Rtj Weld Neck Flange
- A182 Gr F347 Ring Type Joint Flanges
- A182 Gr F304L Rtj Blind Flange
- A182 Gr F316L Ring Type Joint Orifice Flange
- A182 Gr F317 Rtj Flange
- A182 Gr F317L Rtj Weld Neck Flange
- A182 Gr F321 Rtj Blind Flange
- A182 Gr F310 Ring Type Joint Weld Neck Flange
- A182 Gr 347 Ring Type Joint Flanges
- Nickel Alloy Rtj Weld Neck Flange
- ASTM B564 Ring Type Joint Weld Neck Flange
- astm b564 uns n06600 Rtj Weld Neck Flange
- astm b564 uns n06625 Weld Neck Ring Type Joint Flange
- astm b564 uns no4400 Rtj Flange
- astm b564 uns n08810 Rtj Weld Neck Flange
- astm b564 uns n08811 Rtj Blind Flange
- astm b564 uns n08825 Ring Type Joint Flanges
- astm b564 uns n04400 Rtj Flange
- astm b564 uns n10276 Ring Type Joint Orifice Flange
- astm b564 uns n10665 Ring Type Joint Weld Neck Flange
- Titanium
Weld Neck Ring Type Joint Flange
- astm b381 grade f2 Ring Type Joint Weld Neck Flange
- astm b381 f5 Ring Type Joint Orifice Flange
- astm b381 f3 Ring Type Joint Flanges
- astm b381 f12 Rtj Flange
- astm b381 f7 Rtj Weld Neck Flange
- Other grades: ASTM B381 F1, F2, F2H, F3, F4, F5, F6, F7, F7H, F9, F10, F11, F12, F13, F14, F15, F16, F16H, F17, F18, F19, F20, F21, F23, F24, F25, F26 , F26H, F27, F28, F29, F30, F31, F32, F33, F34, F35, F36, F37, F38 Rtj Blind Flange
Dimensions of Ring Type Joint Orifice Flange
Weight Chart Of Rtj Blind Flange
| NPS (Inches) |
DN (mm) |
FLANGE OD A MM |
FLANGE THICKNESS D MM |
SLIP ON FLANGE WEIGHT (KGS) | WELD NECK FLANGE WEIGHT (KGS) | BLIND FLANGE WEIGHT (KGS) |
| 1/ 2 | 15 | 88.9 | 11.2 | 0.4 | 0.5 | 0.4 |
| 3/ 4 | 20 | 98.6 | 12.7 | 0.6 | 0.7 | 0.6 |
| 1 | 25 | 108 | 14.2 | 0.8 | 1 | 0.9 |
| 1 1/ 4 | 32 | 117.3 | 15.7 | 1 | 1.3 | 1.2 |
| 1 1/ 2 | 40 | 127 | 17.5 | 1.3 | 1.7 | 1.5 |
| 2 | 50 | 152.4 | 19.1 | 2.1 | 2.6 | 2.4 |
| 2 1/ 2 | 65 | 177.8 | 22.4 | 3.3 | 4.1 | 3.9 |
| 3 | 80 | 190.5 | 23.9 | 3.9 | 4.9 | 4.9 |
| 3 1/ 2 | 90 | 215.9 | 23.9 | 4.8 | 6.1 | 6.2 |
| 4 | 100 | 228.6 | 23.9 | 5.3 | 6.8 | 7.0 |
| 5 | 125 | 254 | 23.9 | 6.1 | 8.6 | 8.6 |
| 6 | 150 | 279.4 | 25.4 | 7.5 | 10.6 | 11.3 |
| 8 | 200 | 342.9 | 28.4 | 12.1 | 17.6 | 19.6 |
| 10 | 250 | 406.4 | 30.2 | 16.5 | 24 | 28.6 |
| 12 | 300 | 482.6 | 31.8 | 26.2 | 36.5 | 43.2 |
| 14 | 350 | 533.4 | 35.1 | 34.6 | 48.4 | 58.1 |
| 16 | 400 | 596.9 | 36.6 | 44.8 | 60.6 | 76.1 |
| 18 | 450 | 635 | 39.6 | 48.9 | 68.3 | 93.7 |
| 20 | 500 | 698.5 | 42.9 | 61.9 | 84.5 | 122.0 |
| 24 | 600 | 812.8 | 47.8 | 86.9 | 115 | 185.0 |
