High Yield Carbon Steel SA 694 F52/F65/ F60/F70 Slip On Flange, ASME SA694 High Yield CS F52 Slip On Flange, ASTM A694 F65 Blind Flange suppliers in India Suppliers In India
ASTM A694 Flange Specification
Specification: ASTM A694 / ASME SA694
Size: 1/2″ to 48″
Schedule: SCH10, SCH 40, SCH 80, SCH 160 To SCH XXS
Dimension Standard: ANSI/ASME B16.5, B 16.47 Series A & B,
B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Type: Ring Joint Flange (RTJ), Flat Face Flange (FF),
Raised Face Flange (RF), Male and Female Flange (M & F),
Lap Joint Flange, Large and Small Tongue-and-Groove Flange (T & G)
Pressure rating: 150#, 300#, 600#, 900#, 1500#, 2500#,
Carbon Steel ASTM A694 flanges are frequently used across industries due to their strong mechanical characteristics and outstanding resilience. These flanges are designed to resist intensive conditions, making them appropriate for projects that involve high temperatures, pressures, and corrosive atmospheres.
ASTM A694 flanges made of Carbon Steel possess excellent resistance to tension. Crafted from carbon steel, this product provides remarkable strength and durability for industrial use. These flanges can withstand great pressures and loads, thus making them ideal to be used in oil and gas businesses as well as vital piping systems. Its high tensile strength provides a reliable and secure link between pipelines and apparatuses.
Distributors Of ASME SA694 High Yield CS F52 Slip On Flange, A694 F60 Threaded Flange, ASTM A694 F52 Blind Raised Flanges, ASTM A694 F70 Flanges, ASTM A694 Flange Dimensions, At Cheap Price
The outstanding corrosion resistance of Carbon Steel ASTM A694 flanges is a noteworthy trait. These flanges are created to defy the effects of deterioration generated by various components, including humidity, substances, and carbon dioxide. This corrosion resilience guarantees the flanges' lastingness and grit, making them ideal to be employed for extended lengths in harsh conditions.
These flanges are highly accurate in dimensions and ensure a secure and leak-proof connection when connecting components. The tight tolerances of Carbon Steel ASTM A694 flanges help lower the possibility of any leakage, safeguarding operations and averting potential risks.
At our company, we take great care in packing Carbon Steel ASTM A694 flanges. We understand the importance of protecting these high-quality products during transportation. Therefore, we use sturdy packaging materials that provide adequate cushioning and support. Our team ensures that each flange is securely placed in the packaging, minimising the risk of damage and ensuring they reach our customers in perfect condition.
ASTM A694 Carbon Steel Flanges Specifications
| Specifications | ASTM A694 / ASME SA694 |
| Dimensions | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
| Standard | ANSI, ASME, BS, DIN, EN etc. |
| Grades | F42, F46, F52, F60, F65, F70, A36, A516 Gr. 70,60 |
| Size | 1/2″ to 48″ |
| Class / Pressure | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
| Flange Face Type | Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
The Carbon Steel ASTM A350 LF2 Flanges come in various sizes, pressure levels, and types, including slip-on, weld neck, blind, and threaded flanges. Their many options make them suitable for a wide range of projects, thus offering the flexibility to meet the demands of any given project.
Carbon Steel ASTM A350 LF2 flanges are packed in tough wooden boxes or cases to guarantee safe transportation and storage. The flanges are precisely arranged and held securely in the packaging to stop any harm or alteration while handling and shipping. This packaging technique provides an additional shield layer and helps keep up the quality of the flanges until they reach their final destination.
Weight Of Carbon Steel A350 LF2 Flanges
| Standard | Class | Diameter | Bolt Circle Diameter | Number of Bolts | Bolt Size | Diameter of Bolt Hole |
|---|---|---|---|---|---|---|
| AS4087 | PN14 | 95 | 67 | 4 | M12 | 14 |
| AS 2129 Flange | Table C | 95 | 67 | 4 | 13 | 14 |
| Table D | 95 | 67 | 4 | 13 | 14 | |
| Table E | 95 | 67 | 4 | 13 | 14 | |
| Table F | 95 | 67 | 4 | 13 | 14 | |
| Table H | 114 | 83 | 4 | 16 | 17 | |
| Table J | 114 | 83 | 4 | 16 | 17 | |
| ANSI B16.5 | ANSI 150 | 89 | 60 | 4 | 13 | 16 |
| ANSI 300 | 95 | 67 | 4 | 13 | 16 | |
| ANSI 600 | 95 | 67 | 4 | 13 | 16 | |
| ANSI 900 | 121 | 83 | 4 | 19 | 22 | |
| ANSI 1500 | 121 | 83 | 4 | 19 | 22 | |
| ISO 7005 (DIN) Flange | PN6 | 80 | 55 | 4 | M10 | 11 |
| PN10 | 95 | 65 | 4 | M12 | 14 | |
| PN16 | 95 | 65 | 4 | M12 | 14 | |
| PN20 | 90 | 60.5 | 4 | M14 | 16 | |
| PN25 | 95 | 65 | 4 | M12 | 14 | |
| PN40 | 95 | 65 | 4 | M12 | 14 |
Material Astm A350 Gr Lf2 Dimensions
| AMERICAN SOCIETY OF MECHANICAL ENGINEERS (ASME) |
|
|---|
A350 LF2 Blind Flange Thermal Properties
| Properties | Metric | Imperial |
|---|---|---|
| Thermal expansion co-efficient (@0-100°C/32-212°F) | 10.4 µm/m°C | 5.78 µin/in°F |
| Thermal conductivity | 21.6 W/mK | 150 BTU in/hr.ft².°F |
Carbon Steel A694 Flanges Chemical Composition
|
Heat Analysis |
Product Analysis |
Carbon, max |
0.26 |
0.265 |
Manganese, max |
1.60 |
1.64 |
Phosphorus, max |
0.025 |
0.030 |
Sulfur, max |
0.025 |
0.030 |
Silicon |
0.15-0.35 |
0.10-0.40 |
ASTM A694 Pipe Flange Mechanical Table
| ASTM A694 Grade | Yield Strength min. | Tensile Strength min. | Elongation min. | ||
| MPa | ksi | MPa | ksi | % | |
| A694 F42 FLANGES | 290 | 42 | 415 | 65 | 20 |
| A694 F46 FLANGES | 315 | 46 | 415 | 60 | 20 |
| A694 F48 FLANGES | 330 | 48 | 425 | 62 | 20 |
| A694 F50 FLANGES | 345 | 50 | 440 | 64 | 20 |
| A694 F52 FLANGES | 360 | 52 | 455 | 66 | 20 |
| A694 F56 FLANGES | 385 | 56 | 470 | 68 | 20 |
| A694 F60 FLANGES | 415 | 60 | 515 | 75 | 20 |
| A694 F65 FLANGES | 450 | 65 | 530 | 77 | 20 |
| A694 F70 FLANGES | 485 | 70 | 565 | 82 | 18 |
ASTM A694 Flange Pressure Ratings
| ASTM/ANSI B 16.36 | Welding Neck, Slip on, Threaded Flange |
| PRESSURE CLASS | 300, 400, 600, 900, 1500, 2500 |
| ASTM/ANSI B 16.5 | Welding Neck, Slip on, Blind, High Hub Blind, Socket Weld, Lap Joint, Threaded, Ring Type Joint Flange |
| PRESSURE CLASS | 150, 300, 400, 600, 900, 1500, 2500 |
| ASTM/ANSI B 16.47 | Welding Neck, Blind Flange [Series A & B] |
| PRESSURE CLASS | 75, 150, 300, 400, 600, 900 |
| BS 4504 SEC 3.1 | Welding Neck, Hubbed Slip on, Hubbed Threaded, Lapped Pipe End, Plate, Loose Plate, Loose Plate With Weld Neck, Blank Flange |
| PRESSURE CLASS | PN 2.5 TO PN 40 |
| BS 4504[PART 1] | Welding Neck, Hubbed Slip-On Hubbed Threaded, Plate, Loose Plate With Weld On Plate Collar, Blank Flange |
| PRESSURE CLASS | PN 2.5 TO PN 400 |
| BS 1560 BOSS | Welding Neck, Socket Welding, Slip-On, Blind, Screwed Boss, Lapped Flange |
| PRESSURE CLASS | 150, 300, 400, 600, 900, 1500, 2500 |
| BS10 | Welding Neck, Plate Slip-On, Screwed Boss, Slip-On Boss, Blind Flange |
| TABLE | D, E, F, H |
| DIN FLANGES | DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673 |
| PRESSURE CLASS | PN 6 TO PN 100 |
